1 Bedroom Mini Cabin

$189.00
Type: Floorplan

This cozy, one-bedroom resort cottage is the perfect little oasis for those who need to get away. Ideal for great outdoors lovers, these frontier cabin plans feature a large living room bordered by floor-to-ceiling windows and a large galley kitchen. With this design, you can enjoy the reverie of nature without being distracted by bugs and humidity. This resort cottage floor plan also includes a covered deck extension for both rooms, allowing you to soak your soul in nature's healing rays.

However, the cabin's focal point is the large bedroom capable of fitting a king-size bed and still maintaining plenty of maneuverability. This room also has a sliding glass door that leads to a covered deck, allowing you to rise with the sun and sip your coffee as you revere towering mountain peaks and watch the cool dewdrops settle on the grass.



Ground floor area: 740 sqft
Dimensions: 41'-5" L X 25'-4" W X 20' H
Bedroom 1: 12´ L X 13'-5" W X 10' H
Livingroom: 15' -1" L X 15' -10" W
Dining room: 5'-6" L X 9´-9" W
Kitchen: 5'-6" L X 9´-9" W
Living room deck: 16'-3" L x 7'-9" W
Bathroom: 10'-11"L x 7'-2"W
Laundry: 3´L x 7'-2"W
HVAC system: Mini-split, HRV, ERV

Custom Layout:  We've designed homes to adapt to your needs. Our custom layout is designed with flexibility in mind, so it can adjust and accommodate any changes or additions you might make down the line.

Garage: The layout can accommodate detached garages with breeze walkways connecting both structures, and we have a garage design that matches this wood series perfectly!

Foundation: The design can accommodate a slab-on-grade foundation.

Contact us if you want more information about the garage and basement; the team will be glad to help out as much as possible.

The walls are 11 1/4" thick and composed of 2x6 studs with cellulose insulation in between, and a layer of 2 1/2" zip panels on the outside create a continuous insulation layer and close all the thermal gaps. We estimate the R-value of these walls to be 33. The roof is made of wood trusses with a raised heel to increase the thickness of the insulation.

This design uses a foundation wall with footings and a concrete slab insulated on the outside. This way, it is possible to use radiant heat supplemented with mini split units. The water heating is contained in the bathroom closet. This design is also available with a slab-on-grade foundation!

The Study Set Includes:


• 12 - 15 sheets of Digital PDF Format Drawings
• Floorplans
• Exterior Elevations
• Foundation Plan
• Building Sections
• Kitchen and Bathroom elevations
• Kitchen Cabinet chart
• Wall details with materials

* Easy upgrade. We will deduct the study set payment when you purchase the construction set.

Designed to help you take the first step toward building your green home, the drawing pack contains everything you need to make informed choices about your home. The drawing pack comes in a digital PDF file and includes 15 sheets of architectural drawings with detailed dimensions. This set can be used to get an exact cost estimate and inquire about the local permit process.

Note * The study set does not grant a license to the user to build the house using these plans. It is intended as a general inquiry and guide.
